Container Liner

The Container Liner is a bulk bag used inside shipping containers to protect and contain products during transport. It helps prevent contamination and preserves product quality, suitable for dry goods or products requiring extra protection.

Container Liner

Container Liners are designed and fabricated for transportation of dry bulk products. No matter how your product is powder, grain, pellet, chip, clinker, etc. This is produced under industrial standard such as ISO9001:2015, ISO14001, GMP & HACCP, Carbon Foot Print and Halal

Rice & Grains

Starch / Sugar

Plastic Pellet / Powder

Minerals

The whole Container Liner made of fabricated multi-layer co-extruded polyeth-ylene film (PE) in tubular form so that the liner has no sealing line along the body which allows Container Liner to protect product completely from moisture and contamination.

Petrochemical Industries

Carbon Black
White Carbon
Pure Terephthalic Acid or PTA
Polyethylene Terephthalate or PET
Polyethylene or PE
Polypropylene or PP
Polyvinyl Chloride or PVC
Calcium Powder

Agricultural Industries

Tapioca Starch
Sugar
Rice
Wet Hide
Animal Meal

Features

Using Container Liner

Using normal palletizing system

Reduce the risk of product contamination
Reduce the loss space for pallet and cost for Jumbo Bag
Reduce cost for cleaning the container

Installation

Container Liner - Bulk Cargo Bag for Containers

The simple practical installation, loading, and unloading with less time consume. More cost effective and environmentally friendly

Loading Process

Pneumatic Loading

Normally, the liner will connect the loading spout to the blowing (or inlet) equipment and connect ventilation spout to dust collector (or outlet) equipment. This system
is implementing to most petrochemical product (which is pellet form).

Gravity Loading

This loading method is suitable for light and powder product such as PVC, starch, or silica powder. By tilting loading, it is the fastest way to fill into liner. However,
construction facilities need to be prepared in advance because silo must be installed at higher level.

Belt Conveying

Belt conveying is the cheapest method in term of investment. Most of agriculture manufactures (such as rice mill) have this equipment in their factory. To adapt
Agricultural Liner will not change their operation much. By simply, install liner, lift 1 ton bag and pour into loading hopper, they can load product as needed.

Unloading Process

The most suitable way to unload product is to generally tilt truck’s chassis at 5 degree up to max 45 degree. The flowing material shall be conveyed through piping system up to customer silo.
