รถยกพาเลทยกสูง
Electric Stacker
The Eclectic Stacker, a high-lifting device, efficiently stores and transports goods. Ideal for use in factories and warehouses, it supports heavy loads and can lift items to significant heights. This equipment increases storage space and simplifies product management, providing convenience and safety in operation
Electric Stacker
Model CDDRD12
-
Fork Size (mm.)570 x 1,150
-
Capacity ( kg.)1,200
-
Min/Max Lifting Height (mm.)90/1,600 , 90/1,950
-
WheelPU
-
Battery12V/80Ah. (2 pcs/unit)
Model T16-40BC
-
Fork Size (mm.)685 X 1,150
-
Capacity (kg.)1,600
-
Min/Max Lifting Height (mm.)85/4,000
-
WheelPU
-
Battery24V/280Ah. (1pc/unit)
Model ES15T4-5500
-
Fork Size (mm.)560 x1,150
-
Capacity ( kg.)1,500
-
Min/Max Lifting Height (mm.)5,500
-
WheelPU
-
Battery24V/270Ah
Electric Straddle Stacker
Model: ESS15D4
-
Fork Size (mm.)200-800x1,070
-
Capacity (kg.)1,500 Min/Max
-
Min/Max Lifting Height (mm.)85/3,000
-
WheelPU
-
Battery24V/280Ah.(1 pc/unit)
Counter Balance Electric Stacker
Model : D16-45
-
Fork Size (mm.)200-600 x 1,070
-
Capacity ( kg.)1,600
-
Min/Max Lifting Height (mm.)4,500
-
WheelPU
-
Battery12V/80Ah. (2pcs/unit)
Model : D12-33
-
Fork Size (mm.)-
-
Capacity (kg.)1,200
-
Min/Max Lifting Height (mm.)3,300
-
WheelPU
-
Battery24V/280Ah. (1pc/unit)
Semi Electric Stacker
Model : CDD15B-III
-
Fork Dimension (mm.)60 x142 x 1,070
-
Capacity (kg.)1,500
-
Min/Max Lifting Height (mm.)85/2,500
-
WheelNylon
-
Battery12V,120Ah (1 pc/unit)
Model : S15-30
-
Fork Dimension (mm.)320 x 830 x 1,150
-
Capacity(kg.)1,500
-
Min/Max Lifting Height(mm.)85/3,000
-
WheelNylon
-
Battery12V,120Ah (1 pc/unit)
Model : DYC15-A30
The semi-electric pallet stacker features electric-powered lifting and manual movement by pushing or pulling. It is ideal for handling and lifting pallets to elevated storage areas.
-
Fork Dimension (mm.)320 x 680 x 1,150
-
Capacity(kg)1,500
-
Min/Max Lifting Height(mm)85/3,300
-
WheelNylon
-
Battery12V,120Ah (1 pc/unit)
Semi Straddle Electric Stacker
Model : DYC15-A3
A semi-electric wide pallet truck designed for lifting wider or larger pallets, with adjustable forks ranging from 108 to 136 centimeters and a lifting height of up to 300 centimeters. It has a load capacity of 1,000 kilograms.
-
Fork Dimension (mm.)60 x 142 x 1,070
-
Capacity (kg.)1,500
-
Min/Max Lifting Height (mm.)85/3,000
-
WheelNylon
-
Battery12V,120Ah (1 pc/unit)
Semi Electric Self-Lift Stacker
Model : VANGO500
A semi-electric self-lifting pallet truck that can engage with the truck bed and lift itself using an electric system, with a load capacity of 500 kilograms.
-
Fork Dimension (mm.)535 x 1150
-
Capacity (kg.)500
-
Min/Max Lifting Height (mm.)85/1300
-
WheelNylon
-
Battery12V,45Ah (AGM battery)
Light Duty Stacker
Model : HS181-25
A lightweight high-lift truck suitable for products with a low weight capacity, capable of lifting forks up to 250 centimeters and supporting a load of 181 kilograms.
-
Fork Size (mm.)630 x 570
-
Capacity (kg.)181
-
Min/Max Lifting Height (mm.)90/2,500
Hand Stacker
Model : SDJ1000, SDJ1500
A high-lift pallet truck or stacker uses a hydraulic lever to lift and lower the forks, moving by pushing or pulling. This compact, lightweight lift truck is easy to maneuver, making it suitable for lifting items to high places, loading products onto trucks or pickups, and transporting goods from the vehicle. It can lift forks up to 300 centimeters.
-
ModelSDJ1,000
-
Fork Size (mm.)580 x 1,150
-
Capacity (kg.)1,000
-
Min/Max Lifting Height (mm.)90/2,500-3,000
-
ModelSDJ1,500
-
Fork Size (mm.)580 x 1,150
-
Capacity (kg.)1,500
-
Min/Max Lifting Height (mm.)70/1,600
Hand Straddle Stacker
Model : SDJAS1500
A high-lift truck with a platform uses a hydraulic foot pedal to raise and lower the platform. It features a hand-operated valve for lowering and moves by pushing or pulling. The truck is compact and lightweight, making it easy to maneuver.
-
Fork Size (mm.)30 x 100 x 1,060
-
Capacity (kg.)1,000
-
Min/Max Lifting Height (mm.)70/1,600
Platform Stacker
Model : PS4150A
A high-lift truck with a platform uses a hydraulic foot pedal to raise and lower the platform. It features a hand-operated valve for lowering and moves by pushing or pulling. The truck is compact and lightweight, making it easy to maneuver.
-
Fork Size (mm.)580 x 1,040 x 1,740
-
Capacity (kg.)400
-
Min/Max Lifting Height (mm.)200 / 1,500
