รถยกพาเลทยกสูง
Electric Stacker

The Eclectic Stacker, a high-lifting device, efficiently stores and transports goods. Ideal for use in factories and warehouses, it supports heavy loads and can lift items to significant heights. This equipment increases storage space and simplifies product management, providing convenience and safety in operation

Electric Stacker

Model CDDRD12
Model CDDRD12
  1. Fork Size (mm.)
    570 x 1,150
  2. Capacity ( kg.)
    1,200
  3. Min/Max Lifting Height (mm.)
    90/1,600 , 90/1,950
  4. Wheel
    PU
  5. Battery
    12V/80Ah. (2 pcs/unit)
Model T16-40BC
Model T16-40BC
  1. Fork Size (mm.)
    685 X 1,150
  2. Capacity (kg.)
    1,600
  3. Min/Max Lifting Height (mm.)
    85/4,000
  4. Wheel
    PU
  5. Battery
    24V/280Ah. (1pc/unit)
Model ES15T4-5500
Model ES15T4-5500
  1. Fork Size (mm.)
    560 x1,150
  2. Capacity ( kg.)
    1,500
  3. Min/Max Lifting Height (mm.)
    5,500
  4. Wheel
    PU
  5. Battery
    24V/270Ah

Electric Straddle Stacker

Model: ESS15D4
Model: ESS15D4
  1. Fork Size (mm.)
    200-800x1,070
  2. Capacity (kg.)
    1,500 Min/Max
  3. Min/Max Lifting Height (mm.)
    85/3,000
  4. Wheel
    PU
  5. Battery
    24V/280Ah.(1 pc/unit)

Counter Balance Electric Stacker

Model : D16-45
Model : D16-45
  1. Fork Size (mm.)
    200-600 x 1,070
  2. Capacity ( kg.)
    1,600
  3. Min/Max Lifting Height (mm.)
    4,500
  4. Wheel
    PU
  5. Battery
    12V/80Ah. (2pcs/unit)
Model : D12-33
Model : D12-33
  1. Fork Size (mm.)
    -
  2. Capacity (kg.)
    1,200
  3. Min/Max Lifting Height (mm.)
    3,300
  4. Wheel
    PU
  5. Battery
    24V/280Ah. (1pc/unit)

Semi Electric Stacker

Model : CDD15B-III
Model : CDD15B-III
  1. Fork Dimension (mm.)
    60 x142 x 1,070
  2. Capacity (kg.)
    1,500
  3. Min/Max Lifting Height (mm.)
    85/2,500
  4. Wheel
    Nylon
  5. Battery
    12V,120Ah (1 pc/unit)
Model : S15-30
Model : S15-30
  1. Fork Dimension (mm.)
    320 x 830 x 1,150
  2. Capacity(kg.)
    1,500
  3. Min/Max Lifting Height(mm.)
    85/3,000
  4. Wheel
    Nylon
  5. Battery
    12V,120Ah (1 pc/unit)
Model : DYC15-A30
Model : DYC15-A30

The semi-electric pallet stacker features electric-powered lifting and manual movement by pushing or pulling. It is ideal for handling and lifting pallets to elevated storage areas.

  1. Fork Dimension (mm.)
    320 x 680 x 1,150
  2. Capacity(kg)
    1,500
  3. Min/Max Lifting Height(mm)
    85/3,300
  4. Wheel
    Nylon
  5. Battery
    12V,120Ah (1 pc/unit)

Semi Straddle Electric Stacker

Model : DYC15-A3
Model : DYC15-A3

A semi-electric wide pallet truck designed for lifting wider or larger pallets, with adjustable forks ranging from 108 to 136 centimeters and a lifting height of up to 300 centimeters. It has a load capacity of 1,000 kilograms.

  1. Fork Dimension (mm.)
    60 x 142 x 1,070
  2. Capacity (kg.)
    1,500
  3. Min/Max Lifting Height (mm.)
    85/3,000
  4. Wheel
    Nylon
  5. Battery
    12V,120Ah (1 pc/unit)

Semi Electric Self-Lift Stacker

Model : VANGO500
Model : VANGO500

A semi-electric self-lifting pallet truck that can engage with the truck bed and lift itself using an electric system, with a load capacity of 500 kilograms.

  1. Fork Dimension (mm.)
    535 x 1150
  2. Capacity (kg.)
    500
  3. Min/Max Lifting Height (mm.)
    85/1300
  4. Wheel
    Nylon
  5. Battery
    12V,45Ah (AGM battery)

Light Duty Stacker

Model : HS181-25
Model : HS181-25

A lightweight high-lift truck suitable for products with a low weight capacity, capable of lifting forks up to 250 centimeters and supporting a load of 181 kilograms.

  1. Fork Size (mm.)
    630 x 570
  2. Capacity (kg.)
    181
  3. Min/Max Lifting Height (mm.)
    90/2,500

Hand Stacker

Model : SDJ1000, SDJ1500
Model : SDJ1000, SDJ1500

A high-lift pallet truck or stacker uses a hydraulic lever to lift and lower the forks, moving by pushing or pulling. This compact, lightweight lift truck is easy to maneuver, making it suitable for lifting items to high places, loading products onto trucks or pickups, and transporting goods from the vehicle. It can lift forks up to 300 centimeters.

  1. Model
    SDJ1,000
  2. Fork Size (mm.)
    580 x 1,150
  3. Capacity (kg.)
    1,000
  4. Min/Max Lifting Height (mm.)
    90/2,500-3,000
  5. Model
    SDJ1,500
  6. Fork Size (mm.)
    580 x 1,150
  7. Capacity (kg.)
    1,500
  8. Min/Max Lifting Height (mm.)
    70/1,600

Hand Straddle Stacker

Model : SDJAS1500
Model : SDJAS1500

A high-lift truck with a platform uses a hydraulic foot pedal to raise and lower the platform. It features a hand-operated valve for lowering and moves by pushing or pulling. The truck is compact and lightweight, making it easy to maneuver.

  1. Fork Size (mm.)
    30 x 100 x 1,060
  2. Capacity (kg.)
    1,000
  3. Min/Max Lifting Height (mm.)
    70/1,600

Platform Stacker

Model : PS4150A
Model : PS4150A

A high-lift truck with a platform uses a hydraulic foot pedal to raise and lower the platform. It features a hand-operated valve for lowering and moves by pushing or pulling. The truck is compact and lightweight, making it easy to maneuver.

  1. Fork Size (mm.)
    580 x 1,040 x 1,740
  2. Capacity (kg.)
    400
  3. Min/Max Lifting Height (mm.)
    200 / 1,500
Interested in our products? Contact us for more details and information !
